Bearing list update reference of 20th/Dec/20182018-12-20 17:56:26
Bearing list update reference of 20th/Dec/2018
1 MOTOR SHAFT SEAL V-RING TYPE-A,V-45A

MOTOR SHAFT SEAL V-RING TYPE-A,V-45A OIL SEAL VA FOR ELECTRICAL MOTOR – STANDARD STYLE , VA SEAL HAS A STRAIGHT BACK FOR MOTOR SHAFT DIAMETER FROM 43 TO 48MM. V-45A OIL SEAL PROFILE DIMENSIONS: INSIDE DIAMENT D=40MM, PROFILE HEIGHT=5MM, PROFILE WIDTH=9MM, SEAL SEAT WIDTH=5.5MM. MATERIAL:

NITRILE RUBBER (NBR) THE TEMPERATURE RANGE VARIES FROM -30°C TO + 120°C. MANUFACTURED BY: INA, SKF, FKM, AIKAN, GBSA, TIMKEN, ERIKS, TTO, KOYO

2 GREASE OUTLET DRAWER ,10021209,WEG GREASE OUTLET DRAWER,10021209,WEG GREASE OUTLET DRAWER FOR WEG-MOTOR FRAME 225-355.
3 GREASE NIPPLE PROTECTION,10362046,WEG GREASE NIPPLE PROTECTION,10362046,WEG APPLICABLE FOR WEG MOTOR FRAME 132-355
4 SHAFT OIL SEAL,TC-40X70X10MM,DOUBLE LIP SHAFT OIL SEAL TC-40X70X10MM RUBBER COVERED DOUBLE LIP WITH GARTER SPRING. INNER DIAMETER 40MM / OUTLER DIAMETER 70MM/ WIDTH 10MM. TYPE TC - TWING LIP, SPRING LOADED, RUBBER COVER. MATERIAL NITRILE RUBBER. FEATURE: STANDARD STEEL REINFORCED RING, STANDARD SPRING, TC-"TWICE CAGE". MANUFACTURE: INA, SKF,FKM, AIKAN, GBSA, TIMKEN, ERIKS, TTO, KOYO
5 SHAFT OIL SEAL,TC-50X80X10MM,DOUBLE LIP SHAFT OIL SEAL TC-50X80X10MM RUBBER COVERED DOUBLE LIP WITH GARTER SPRING. INNER DIAMETER 50MM / OUTLER DIAMETER 80MM/ WIDTH 10MM. TYPE TC - TWING LIP, SPRING LOADED, RUBBER COVER. MATERIAL NITRILE RUBBER. FEATURE: STANDARD STEEL REINFORCED RING, STANDARD SPRING, TC-"TWICE CAGE". MANUFACTURE: INA, SKF, FKM, AIKAN, GBSA, TIMKEN, ERIKS, TTO, KOYO
6 SHAFT OIL SEAL,AS30X47X7,SIEMENS SHAFT OIL SEAL,AS30X47X7,SIEMENS DRIVE END AND NON-DRIVE END SEAL APPLICABLE FOR SIEMENS MOTORS 1LE15011BB234JA4-Z
7 SHAFT OIL SEAL,50000531000016,SIEMENS SHAFT OIL SEAL,50000531000016,SIEMENS DRIVE END SEAL APPLICABLE FOR SIEMENS MOTROS 1LA6113-4AA61-Z
8 SHAFT OIL SEAL,50000531000015,SIEMENS SHAFT OIL SEAL,50000531000015,SIEMENS DRIVE END AND NON-DRIVE END SEAL APPLICABLE FOR SIEMENS MOTORS 1LA7130-6AA10-Z
9 PRELOADING WASHER,50000217000003,SIEMENS PRELOADING WASHER,50000217000003,SIEMENS APPLICABLE FOR SIEMENS MOTORS 1LA7130-6AA10-Z
10 BEARING,6301-2Z/C3WT BEARING 6301-2Z/C3WT. SHIELDED DEEP GROOVE BALL BEARINGS. SIZE (MM) 12X37X12MM - INSIDE DIAMETER X OUTSIDE DIAMETER X THICKNESS. SINGLE ROW DEEP GROOVE BALL BEARING WITH TWO METAL SHIELDS, C3 CLEARANCE & HIGH TEMP GREASE -40 TO +160 DEGC.
11 BEARING,6303-2Z/C3WT BEARING 6303-2Z/C3WT. SHIELDED DEEP GROOVE BALL BEARINGS. SIZE (MM) 17X47X14MM - INSIDE DIAMETER X OUTSIDE DIAMETER X THICKNESS. SINGLE ROW DEEP GROOVE BALL BEARING WITH TWO METAL SHIELDS, C3 CLEARANCE & HIGH TEMP GREASE -40 TO +160 DEGC
12 TERMINAL BLOCK,70X45 6P,SEFAL TERMINAL BLOCK 70X45 WITH 6 INSERTS M6 LENGTH/WIDTH/HEIGHT = 70X45X31MM STANDARD BRASS 6 INSERTS ( PINS) DIAMENTER 6MM, H=20MM. DISTANCE INSERT-TO-INSERT 25MM. TERMINAL BLOCK IS MADE OF HIGH-QUALITY PLASTIC THAT IS UL-94 V-0 FLAMMABILITY CLASSIFICATION COMPLIANT.IT IS SUPPLIED FULLY MOUNTED, EQUIPPED WITH NUTS, RINGS AND CONNECTING STRIPS. - DISTANCE HOLE-TO-HOLE 25MM.
13 MOTOR FAN FOR 225/250 FRAME,10016934,WEG MOTOR FAN FOR 225/250 FRAME,10016934,WEG. PLASTIC FAN FOR WEG W21 SERIES MOTOR. FAN FOR MOTOR IEC FRAME 225-250. FAN MATERIAL - PLASTIC (POLYPROPYLENE). DIMENSIONS: OUTSIDE DIAMETER 295MM, HUB DIAMETER 65MM, WIDH 77MM.
14 TERMNL BLOCK,249A8206LJ1,HYUNDAI

Terminal Block,Part # 249A8206LK2 for motors Hyundai Type HLS131UR259CERL Frame №132S, 5.5kW, B5, 400V,Exn II A / Type PNS113SR259THS

Frame №112M,2.2kW, B3, 400V,Exn II A / Type
